Jumlah kabel
|
|
|
|
48
|
|||
|
Model Serat
|
|
|
|
G652D
|
|||
|
Pusat
Anggota Kekuatan |
Bahan
|
|
|
FRP
|
|||
|
|
Diameter (±0,05) mm
|
|
|
1.5
|
|||
|
Tabung longgar
|
Bahan
|
|
|
PBT
|
|||
|
|
Diameter (±0,06) mm
|
|
|
1.8
|
|||
|
|
Ketebalan (±0,03) mm
|
|
|
0,32
|
|||
|
|
Max.Core NO./Tube
|
|
|
12
|
|||
|
Tali pengisi
|
Bahan
|
|
|
LDPE
|
|||
|
|
Diameter (±0,06) mm
|
|
|
1.8
|
|||
|
Lapisan Penghalang Air
|
|
|
|
Kompleks Banjir
|
|||
|
Anggota Kekuatan Tambahan
|
|
|
|
Benang Aramid
|
|||
|
Sarung Dalam
|
Bahan
|
|
|
pe
|
|||
|
|
Ketebalan (±0,1) mm
|
|
|
0,9
|
|||
|
Sarung Luar
|
Bahan
|
|
|
pe
|
|||
|
|
Ketebalan (±0,1) mm
|
|
|
1.7
|
|||
|
Diameter Kabel (±0,2) mm
|
|
|
|
12
|
|||
|
Berat Kabel (±5)kg/km
|
|
|
|
108
|
|||
|
Kekuatan putus kabel (RTS)
|
|
|
|
5.8Kn
|
|||
|
Tegangan Kerja (MAT)
|
|
|
|
2.2Kn
|
|||
|
Kecepatan angin
|
|
|
|
30 m/dtk
|
|||
|
Lapisan gula
|
|
|
|
5mm
|
|||
|
Menjangkau
|
|
|
|
100m
|
|||
|
Hancurkan Perlawanan
|
|
|
Jangka pendek
|
2200(N/100mm)
|
|||
|
|
|
|
Jangka panjang
|
1100(N/100mm)
|
|||
|
Min.radius lentur
|
|
Tanpa Ketegangan
|
|
10.0×Kabel-φ
|
|||
|
|
|
Di bawah Ketegangan Maksimum
|
|
20.0×Kabel-φ
|
|||
|
Kisaran suhu
(℃) |
|
Instalasi
|
|
-20~+60
|
|||
|
|
|
Transportasi & Penyimpanan
|
|
-40~+70
|
|||
|
|
|
Operasi
|
|
-40~+70
|
|||
